型号：
RC(底角安装): RC01,RC02,RC03,RC04
RCF(B5 法兰安装: RCF01,RCF02,RCF03,RCF04
RCZ(B14 Flange-mounted): RCZ01,RCZ02,RCZ03,RCZ04
参数:
|
型号 |
功率 |
速比 |
最大扭矩 |
||||||
|
01,02,03,04 |
0.12kW~4kW |
3.66~54 |
120N.m~500N.m |
||||||
|
选型表 |
|
||||||||
|
RC01.. |
|
|
|
n1=1400r/min |
|
|
|
120Nm |
|
|
n2 |
M2max |
Fr2 |
i |
Proportion |
63B5 |
71B5/B14 |
80B5/B14 |
90B5/B14 |
|
|
[r/min] |
[Nm] |
[N] |
|
||||||
|
26 |
120 |
2600 |
53.33 |
160/3 |
|
|
|
|
|
|
31 |
120 |
2600 |
45.89 |
413/9 |
|
|
|
|
|
|
35 |
120 |
2600 |
40.10 |
3248/81 |
|
|
|
|
|
|
39 |
120 |
2560 |
35.47 |
532/15 |
|
|
|
|
|
|
49 |
120 |
2380 |
28.50 |
770/27 |
|
|
|
|
|
|
59 |
120 |
2230 |
23.56 |
212/9 |
|
|
|
|
|
|
71 |
120 |
2100 |
19.83 |
119/6 |
|
|
|
|
|
|
78 |
90 |
2030 |
17.86 |
1357/76 |
|
|
|
|
|
|
96 |
120 |
1900 |
14.62 |
658/45 |
|
|
|
|
|
|
101 |
90 |
1860 |
13.80* |
69/5 |
|
|
|
|
|
|
118 |
120 |
1770 |
11.90 |
2464/207 |
|
|
|
|
|
|
143 |
120 |
1660 |
9.81 |
1148/117 |
|
|
|
|
|
|
153 |
80 |
1630 |
9.17 |
1219/133 |
|
|
|
|
|
|
181 |
80 |
1540 |
7.72 |
1173/152 |
|
|
|
|
|
|
246 |
70 |
1390 |
5.69 |
1081/190 |
|
|
|
|
|
|
302 |
70 |
1290 |
4.63 |
88/19 |
|
|
|
|
|
|
366 |
70 |
1210 |
3.82 |
943/247 |
|
|
|
|
|
|
RC02.. |
|
|
|
n1=1400r/min |
|
|
|
200Nm |
|
|
n2 |
M2max |
Fr2 |
i |
Proportion |
63B5 |
71B5/B14 |
80B5/B14 |
90B5/B14 |
|
|
[r/min] |
[Nm] |
[N] |
|
||||||
|
26 |
200 |
4500 |
54.00* |
54/1 |
|
|
|
|
|
|
30 |
200 |
4500 |
46.46* |
3717/80 |
|
|
|
|
|
|
34 |
200 |
4500 |
40.60* |
203/5 |
|
|
|
|
|
|
39 |
200 |
4270 |
35.91* |
3591/100 |
|
|
|
|
|
|
48 |
200 |
3970 |
28.88* |
231/8 |
|
|
|
|
|
|
59 |
200 |
3730 |
23.85* |
477/20 |
|
|
|
|
|
|
70 |
200 |
3520 |
20.08* |
3213/160 |
|
|
|
|
|
|
82 |
140 |
3330 |
17.10 |
3009/176 |
|
|
|
|
|
|
95 |
200 |
3180 |
14.81* |
2961/200 |
|
|
|
|
|
|
106 |
140 |
3060 |
13.21 |
2907/220 |
|
|
|
|
|
|
116 |
200 |
2970 |
12.05 |
1386/115 |
|
|
|
|
|
|
141 |
200 |
2780 |
9.93 |
2583/260 |
|
|
|
|
|
|
159 |
120 |
2670 |
8.78 |
2703/308 |
|
|
|
|
|
|
189 |
120 |
2520 |
7.39 |
2601/352 |
|
|
|
|
|
|
257 |
100 |
2280 |
5.45 |
2397/440 |
|
|
|
|
|
|
316 |
100 |
2120 |
4.43 |
102/23 |
|
|
|
|
|
|
383 |
80 |
1990 |
3.66 |
2091/572 |
|
|
|
|
|
|
RC03.. |
|
|
|
n1=1400r/min |
|
|
|
|
300Nm |
|
n2 |
M2max |
Fr2 |
i |
Proportion |
71B5/B14 |
80B5/B14 |
90B5/B14 |
100B5/B14 |
112B5/B14 |
|
[r/min] |
[Nm] |
[N] |
|||||||
|
24 |
300 |
6000 |
58.09 |
639/11 |
|
|
|
|
|
|
28 |
300 |
6000 |
50.02 |
2201/44 |
|
|
|
|
|
|
32 |
300 |
6000 |
43.75 |
4331/99 |
|
|
|
|
|
|
36 |
300 |
6000 |
38.73 |
426/11 |
|
|
|
|
|
|
40 |
300 |
5860 |
34.62 |
4189/121 |
|
|
|
|
|
|
49 |
300 |
5480 |
28.30 |
4047/143 |
|
|
|
|
|
|
64 |
280 |
5020 |
21.78 |
1917/88 |
|
|
|
|
|
|
81 |
280 |
4660 |
17.33 |
3621/209 |
|
|
|
|
|
|
93 |
260 |
4440 |
15.06 |
497/33 |
|
|
|
|
|
|
113 |
260 |
4160 |
12.37 |
1633/132 |
|
|
|
|
|
|
136 |
240 |
3910 |
10.28 |
3053/297 |
|
|
|
|
|
|
177 |
180 |
3590 |
7.93 |
1269/160 |
|
|
|
|
|
|
222 |
180 |
3320 |
6.31 |
2397/380 |
|
|
|
|
|
|
255 |
150 |
3170 |
5.48 |
329/60 |
|
|
|
|
|
|
311 |
150 |
2970 |
4.50 |
1081/240 |
|
|
|
|
|
|
374 |
150 |
2790 |
3.74 |
2021/540 |
|
|
|
|
|
|
RC04.. |
|
|
|
n1=1400r/min |
|
|
|
500Nm |
|
|
n2 |
M2max |
Fr2 |
i |
Proportion |
80B5/B14 |
90B5/B14 |
100B5/B14 |
112B5/B14 |
|
|
[r/min] |
[Nm] |
[N] |
|||||||
|
24 |
500 |
8000 |
58.09 |
639/11 |
|
|
|
|
|
|
28 |
500 |
8000 |
50.02 |
2201/44 |
|
|
|
|
|
|
32 |
500 |
8000 |
43.75 |
4331/99 |
|
|
|
|
|
|
36 |
500 |
8000 |
38.73 |
426/11 |
|
|
|
|
|
|
40 |
500 |
7950 |
34.62 |
4189/121 |
|
|
|
|
|
|
49 |
500 |
7430 |
28.30 |
4047/143 |
|
|
|
|
|
|
64 |
480 |
6810 |
21.78 |
1917/88 |
|
|
|
|
|
|
81 |
480 |
6310 |
17.33 |
3621/209 |
|
|
|
|
|
|
93 |
460 |
6020 |
15.06 |
497/33 |
|
|
|
|
|
|
113 |
460 |
5640 |
12.37 |
1633/132 |
|
|
|
|
|
|
136 |
440 |
5300 |
10.28 |
3053/297 |
|
|
|
|
|
|
177 |
260 |
4860 |
7.93 |
1269/160 |
|
|
|
|
|
|
222 |
260 |
4510 |
6.31 |
2397/380 |
|
|
|
|
|
|
255 |
230 |
4300 |
5.48 |
329/60 |
|
|
|
|
|
|
311 |
230 |
4030 |
4.50 |
1081/240 |
|
|
|
|
|
|
374 |
200 |
3780 |
3.74 |
2021/540 |
|
|
|
|
|
